C118 Construction Dump Wagons

C118 Construction Dump Wagons


Struck Capacity
225ft³ | 6.4m³
Heaped Capacity
380ft³ | 10.8m³
Max Weight Capacity
37600lbs | 17100kg
Box Height
26in | 66cm
Box Floor Length
144in | 366cm
Box Top Length
191in | 485cm
Box Width Front
68in | 173cm
Box Width Rear
72in | 183cm
Overall Height
80in | 203cm
Overall Length
271in | 688cm
Overall Width
101in | 257cm
Loading Height
80in | 203cm
Tongue Style
Solid HD
Dumping Angle
Cycle Time
Floor Material
Floor Thickness
3/8in | 9.5mm
Wall Material
Wall Thickness
1/4in | 6mm
Empty Weight
10,000lbs | 4540kg
Standard Tires
445/65 R22.5 RADIAL (2)
Recommended Tires
700/40 22.5 BIAS (2)
Wheel Assembly
Single Straight Axle
Lift Cylinders Type
Single Double-Acting
Oil From Tractor
1.32GAL | 5L
Recommended Tractor Class
Pit-Run Gravel Heaped Capacity
37600lbs | 17100kg
Top Soil Heaped Capacity
28400lbs | 12900kg
Wet Sand Heaped Capacity
36700lbs | 16600kg
Beef Manure Heaped Capacity
19200lbs | 8700kg


Industry Leading

The Jaylor MMI mixer does a phenomenal job of handling wet distillers grains along with both high roughage rations and high energy corn rations.

Scott Schiff
Schiff Farms Inc.

Our Jaylor manure spreader is easy on horsepower and retains a lot of moisture. It's built for rugged terrain, and it's stood the test of time. We're thrilled with the performance.

Rob Sutton
Sutton Farm

Jaylor’s C118 Construction Trailer is engineered to be simple and robust, providing years of trouble free performance in demanding commercial, continuous-run applications. Wet conditions are no match for the wide footprint tires which provide excellent stability and low compaction reducing damage allowing operation where trucks can’t travel. Shorter cycle times and high maneuverability mean operators are able to be more productive; transporting larger amounts of material in a shorter time frame.

Standard Features

Commercial Brakes
HD Raised Hinge
Manual Holder


Heavy Duty Walking Beam Axle
Durable 44W Steel Body with heavier floor
Double-acting Cylinders for Rapid Box Decent
Single Swivel Hitch
Wood Protection Rails
Protected LED Road Lights
7 Position Adjustable Axle
Safety Chains
Tapered Body for Easy Unloading
Manual Implement Jack
