5100 Mini TMR Mixer

5100 Mini TMR Mixer

5100 Self-Propelled
5100 Trailer
5100 Stationary
5100 Truck Mount
Capacity No Extension91ft³ | 2.58m³91ft³ | 2.58m³91ft³ | 2.58m³91ft³ | 2.58m³
Weight2280lbs | 1035kg1730lbs | 785kg1850lbs | 839kg1530lbs | 695kg
Height72.5in | 1.85m77in | 1.96m69in | 1.75m69in | 1.75m
Width48.5in | 1.23m55.5in | 1.41m55.5in | 1.41m62.5in | 1.59m
Length129in | 3.28m146in | 3.71m101.5in | 2.58m101.5in | 2.58m
Number Of Knives26262626
Drum MaterialPolyethylenePolyethylenePolyethylenePolyethylene
Drum Thickness0.43in | 10.9mm0.43in | 10.9mm0.43in | 10.9mm0.43in | 10.9mm
Door Width18in | 45.7cm18in | 45.7cm18in | 45.7cm18in | 45.7cm
Door Height22in | 55.9cm22in | 55.9cm22in | 55.9cm22in | 55.9cm
Discharge Height14.5in | 36.83cm16in | 40.6cm12in | 30.5cm5in | 12.7cm
FrameGalvanized SteelGalvanized SteelGalvanized SteelGalvanized Steel
Standard Drive22 HP Honda Gas Engine22 HP Honda Gas Engine(2) 1-Phase 10 HP Electric Motors22 HP Honda Gas Engine
Scale SystemDG STAD 02DG STAD 02DG STAD 02DG STAD 02
View DetailsView DetailsView DetailsView Details
above tabs

Jaylor Mini TMR Mixers have proven themselves ideal for a wide range of applications, including feeding smaller dairies, specialty groups such as weaned calves, dry cows, maternity pens, fresh cows on larger dairy farms, as well as supplemental feeding of beef cows during calving. The New 5150 Mini-Mixer is no exception. At only 86” tall, even the smallest skid steers won’t have any trouble loading this 155 cubic foot (4.4m3) model and just 35 Horsepower will run it. We’ve used our decades of experience building larger TMR mixers to engineer the same capabilities and durability into this model. The 5150 is equipped with our patented Square-Cut augers which consistently produce a uniform Total Mixed Ration with optimum shaker box results. So why, you might ask? Because Nutrition Matters.

5100 Self Propelled Mixer:

  • Honda GX690 22 HP Gas Engine w/ Electric Start
  • Manual Door w/ Discharge Chute
  • 4 Point Weigh System
  • Polyethylene Drum: ¼” Reinforced Steel Floor
  • Galvanized Steel Frame
  • Sloped Top Square Cut Auger
  • Stainless Steel Angling Blade
  • Auger On/Off & Engine Throttle
  • Hydrostatic All-Wheel Drive w/ Dynamic Braking
  • Dedicated Pumps for Auger and Wheel Drive
  • Pedal Control System for brakes, direction, speed
  • Zero Degree Turning Capability

5100 Trailer Mixer:

  • Honda GX690 22 HP Gas Engine w/ Electric Start
  • Hydraulic Door W/ Discharge Chute
  • Remote Control for Auger & Door
  • 4 Point Weigh System
  • Polyethylene Drum: ¼” Reinforced Steel Floor
  • Galvanized Steel Frame
  • Sloped Top Square Cut Auger
  • Stainless Steel Angling Blade
  • Pin Hitch

5100 Stationary Mixer:

  • 10 HP 1 PH 230 VAC Motor
  • Manual Door w/ Discharge Chute
  • 4 Point Weigh System
  • Sloped Top Square Cut Auger
  • Stainless Steel Angling Blade
  • Polyethylene Drum: ¼” Reinforced Steel Floor
  • Galvanized Steel Frame
  • Hydraulic Control Valve for Auger

5100 Truck Mount Mixer:

  • Honda GX390 22 HP Gas Engine w/ Electric Start
  • Hydraulic Door w/ Discharge Chute
  • 4 Point Weigh System
  • Polyethylene Drum: ¼” Reinforced Steel Floor
  • Galvanized Steel Frame
  • Sloped Top Square Cut Auger
  • Stainless Steel Angling Blade
  • Remote Control for Auger & Door
  • Underframe Tie-Down Mounting Brackets
  • Easily Maneuvered & Installed on Flatbed Truck
