2000 SERIES HORIZONTAL TMR MIXERS
Jaylor’s patented Horizontal Mixers with Ribbon Augers are designed to mix faster and deliver a uniform ration while maintaining flake integrity and eliminating feed compaction during mixing. By allowing feed to circulate and tumble between the ribbons and the inner auger tube, ingredients move freely through the mix chamber instead of being forced along the auger flights.
The result is a faster, more consistent mix without feed degradation or the excessive
fuel consumption and component strain caused by compaction. Designed to deliver
consistent intake, predictable performance, and more efficient feeding.
Have questions, or need to find a dealer in your area?
We’re here to discuss your needs & help you find the right mixer for your operation.
Jaylor 2000 Series Horizontal TMR Mixers
Jaylor H2650 Horizontal Mixer
*Capacity:
700ft³ | 19.8m³
Ration Capacity:
21500lbs | 9700kg
Overall Weight Without Truck:
15400lbs | 6990kg
Overall Height Without Truck:
92in | 234cm
Overall Length Without Truck:
232in | 590cm
Overall Width Without Truck:
102in | 260cm
Height on Typical Truck:
131in | 332cm
Length on Typical Truck:
364in | 925cm
Recommended Truck Engine:
260 HP
Jaylor H2850 Horizontal Mixer
*Capacity:
850ft³ | 24.1m³
Ration Capacity:
26000lbs | 11800kg
Overall Weight Without Truck:
18000lbs | 8160kg
Overall Height Without Truck:
98in | 249cm
Overall Length Without Truck:
256in | 650cm
Overall Width Without Truck:
102in | 259cm
Height on Typical Truck:
137in | 348cm
Length on Typical Truck:
388in | 985cm
Recommended Truck Engine:
300 HP
Jaylor H2950 Horizontal Mixer
*Capacity:
950ft³ | 26.9m³
Ration Capacity:
30000lbs | 13500kg
Overall Weight Without Truck:
17800lbs | 8070kg
Overall Height Without Truck:
103in | 262cm
Overall Length Without Truck:
256in | 650cm
Overall Width Without Truck:
108in | 274cm
Height on Typical Truck:
142in | 360cm
Length on Typical Truck:
388in | 986cm
Recommended Truck Engine:
360 HP
Capacities noted above will vary with the density of the hay in the bales and other factors.
We’re here to discuss your needs and help you find the right mixer for your operation.
Have questions?
Unsure what machine is right for your operation?
Need to find a dealer or schedule a demo?
Jaylor’s Horizontal Quad, 4-auger TMR mixers are designed and built by cattlemen for cattlemen. Our years of experience with feedlot rations guarantees you the perfect mixer for your needs. Our Models H2650, H2850 and H2950 provide you with the right capacity and speed. All models are designed and built with the same rugged construction delivering extreme strength without excess weight. Our modern components provide finger touch control to assure power and performance that deliver feed accurately and efficiently. With the best warranty and customer service in the industry, your choice of one of our mixers will long be rewarded.
- Quad 4-Auger
- Hydrostatic Pump
- Hydrostatic Planetary Drive
- Single Joystick Control
- Hydraulic Reservoir
- Mixer Body
- Oil Resistant Door Seals
- Gravity Discharge Chute
- High Capacity Door
- Central Grease Ports
- Adjustable Chute Control
- Remote Scale Display — LED Lights
- OrbitEVO Intelligent Controller
- Oil Bath Auger Drive
Having a 13,000 head feedlot means we throw a lot at our Jaylor mixer. We use french fries in our feed, and the Jaylor 51250HD TMR Mixer gives us the best consistency of mix and vehicle maneuverability. – Piet Heger, Kasko Cattle Co Ltd.
Our Jaylor 5850 Mixer is the fifth Jaylor Mixer we’ve owned. We like to keep current with the latest technology, and the consistent mix and feed from the machine keep us coming back. Choosing anything else would be a step backward for us. – Peter Armstrong, Armstrong Manor Farm
Jaylor Horizontal TMR Mixers FAQs
Jaylor’s Horizontal Quad, 4-auger TMR mixers are specially designed for cattlemen by cattlemen, ensuring they meet the specific needs of feedlot rations. These mixers are known for their rugged construction, providing extreme strength without excess weight, and are equipped with modern components for efficient feed delivery.
The available models for Jaylor’s Horizontal Quad TMR Mixers include the H1650, H1850, and H1950. Each model is designed to provide the right capacity and speed for various feedlot operations.
- These mixers come with a range of features, including:
- Quad 4-Ribbon-Auger system
- Hydrostatic Pump and Planetary Drive
- Single Joystick Control
- Hydraulic Reservoir
- Oil Resistant Door Seals
- Gravity Discharge Chute
- High Capacity Door
- Central Grease Ports
- Adjustable Chute Control
- Remote Scale Display with LED Lights
- OrbitEVO Intelligent Controller
- Oil Bath Auger Drive
Jaylor’s mixers are praised for their consistent mix quality and vehicle maneuverability. They also come with the best warranty and customer service in the industry, ensuring long-term satisfaction and reliability. Customers have noted the consistent mix and feed quality as key reasons for their continued use of Jaylor mixers.
We provide exceptional customer support, including an on-call team for after-hours emergencies. Our full parts inventory ensures quick order responses, often shipping within 24 hours. We maintain a high fill rate for production items and have added a Chicago warehouse to expedite shipments. For support, you can reach our service team at 800.800.8224 or service@jaylor.com.
