M1600 HD Commercial Manure Spreader

M1600 HD Commercial Manure Spreader

Specifications

Struck Capacity
600ft³ | 17.0m³
Heaped Capacity
1000ft³ | 28.3m³
Overall Height
140in | 356cm
Overall Length
375in | 953cm
Overall Width
138in | 351cm
Inside Body Height
50in | 127cm
Inside Body Length
240in | 610cm
Inside Body Width
78in | 198cm
Loading Height
111in | 282cm
Pto Speed
1000 RPM
Beater Speed
405 RPM
Recommended Tractor Class
150-250 HP
Floor Thickness
1/4in | 6mm
Side Wall Thickness
3/16in | 4.8mm
Standard Tires
445/65 R22.5 Radial
Recommended Tires
800/45 26.5 BIAS
Standard Wheel Assembly
Tandem Walking Beam

Warranty

Industry Leading

Our Jaylor manure spreader is easy on horsepower and retains a lot of moisture. It's built for rugged terrain, and it's stood the test of time. We're thrilled with the performance.

Rob Sutton
Sutton Farm

We have a Jaylor 5575, and it's our second piece of Jaylor equipment. We've only had to do regular maintenance on the machine, which makes using the mixer simple and convenient.

Richard Dean
Ash Grove, Missouri

Built with simplicity and specifications tailored to conquer rugged terrain for more extensive operations, Jaylor’s M1600 HD manure spreader is made to stand up to the test of time.

The Jaylor M1600 HD Manure Spreader offers the second-largest holding capacity of the entire Jaylor Manure Spreader line. Operators enjoy the increased heap capacity of 1000ft3 aired with a 600ft3 struck capacity, allowing them a generous increase of spreading volume.

Quick-attach vertical beaters and a hydraulic guillotine door allow The Jaylor M1600 HD spreader to achieve a full 40′ of consistent spread from both to back and cross the width of the spreader.

Each beater is reinforced with 2-1/4″ bearings, allowing the spreader to withstand regular abuse from large stone, frozen chunks and other debris commonly found within a typical spread.

Commercial-grade highway axles, breaks, and oil bath hubs are all standard equipment for the Jaylor M1600 HD, allowing peace of mind and virtually zero maintenance concerns for operators.

After using the M1600 HD manure spreader for only a few minutes, you’ll understand why Jaylor says: “Because Simplicity Matters.”

Features of M1600 HD manure spreader

  • Hydraulic Brakes
  • Overrun Clutch Gearbox Protection
  • High-Speed Cambered Commercial Axles
  • Manual Implement Jack
  • Wood Protection Rail
  • Large Viewing Window
  • Spring Suspension Tongue
  • LED Road Lights
  • Dual Floor Chain Drive Gearboxes
  • Commercial Grade Tubular Chassis
  • Grade 100 Floor Chain w/ One Piece Slat
  • Heavy Duty Walking Beam Axle
  • 7 Position Adjustable Axle
  • Saftey Chain

Standard Features

HD RT1000 Floor Chain Drive
HD Spring-loaded Tongue
Rear Beater Assembly Unhooked
Rear Beater Assembly Hooked
